多重網路 提升覆蓋率
「電力線(無線)網路橋接器」提供多重網路：電力線網路＋無線網路＋乙太網路，能讓家中/辦公室插座變成網路熱點，提升網路覆蓋率，無論身在何處，都能享受高速穩定的網路連線。
智慧網路 無線延伸
完成安裝後，只要將電力線無線網路橋接器插上插座，即可建立WiFi無線網路熱點，客廳、房間、廚房...任何地方都能享受高速網路，智慧家庭不斷線
免拉網路線 快速安裝 立即上網
1.將電力線網路橋接器(G701)插於牆壁插座並透過網路線連接ADSL路由器
2.將電力線無線網路橋接器(G750)亦插於牆壁插座
3.網路設備(電腦、手機、平板...)連上G750 WiFi，立即無限上網！
智慧家庭 一手掌握
下載 APP，即可加入所有不同類別的智慧裝置隨心控制、盡在指尖
手機設定
手機APP即可設定網路
網路管理
查看連線狀態
密碼管理
手機APP設定WiFi密碼
下載 APP
現在就免費下載，開始享受你的智慧生活
網速超快
讓您觀看HD高畫質影音不lag；暢玩線上遊戲不間斷
加密超安全
128-bit AES加密，資安維護不馬虎規格
| Model No. | G701 | G711 | G750 | G780 | G781 |
|---|---|---|---|---|---|
| Product Name | PLC Adapter | SmartLINK PLC Adapter | Hotspot Hybrid Adapter(WiFi+PLC) | 1 port PLC Plugthrough Adapter | 3 Ports PLC Plugthrough Adapter |
| PHY Rate | 600Mbps | ||||
| Effect Data Rate | TCP: ≤ 95 Mbps effective throughput UDP: ≤ 95 Mbps effective throughput |
||||
| Frequency Band | 2~68 MHz (With Mask) | ||||
| 95% Coverage UDP Throughput | 30Mbps | ||||
| Access Methods | Priority-based CSMA/CA channel access | ||||
| QoS | 4 Levels priority based contention access and multi segment bursting 8-levels VLAN priority field, TOS Field QoS Classification by destination MAC address and IP Port |
||||
| Modulation | OFDM (QAM 8/16/64/256/1024, QPSK, BPSK, ROBO) | ||||
| Nodes | Up to 7 PLC devices in 1 power circuit | ||||
| IGMP | Support for IPv4/IGMPv1,v2,v3 snooping Support for IPv6 and MLDv1,v2 snooping Max 16 source addresses and Group Members |
||||
| Encryption | 128-bit AES Link Encryption with key management | ||||
| Standards | IEEE 802.3, IEEE 802.3U, IEEE1901 and HomePlug AV2 compliant | ||||
| Port | One 10/100M Ethernet port | ||||
| Distance | AC Wire : 300 meters | ||||
| LEDs | Power Indicator(Green) Powerline Indicator (Green/Orange/Red) Ethernet Indicator (Green) |
Power Indicator (Green) Powerline Indicator (Green/Orange/Red) Ethernet Indicator (Green) WiFi Indicator(Green) |
Power Indicator (Green) Powerline Indicator (Green/Orange/Red) Ethernet Indicator (Green) |
Power Indicator (Green) Powerline Indicator (Green/Orange/Red) Ethernet 1,2,3 Indicator (Green) |
|
| Temperature (Humidity) |
Operating : 5~40°C(10~90% Non-Condensing) Storage : 0~50°C(5~90% Non-Condensing) |
||||
| Power Source | 100-240 VAC, 50/60 Hz, 0.1A | 100-240 VAC, 50/60 Hz, 0.2A | 100-240 VAC, 50/60 Hz, 0.1A | ||
| Push Button | Setting button for Network Security Management Reset button |
Setting/PLC Reset Button WPS/ WiFi Reset Button |
Setting button for Network Security Management Reset button |
||
| WiFi Standards | N/A | N/A | IEEE 802.11n, IEEE 802.11g, IEEE 802.11b 64/128/152-bit WEP/WPA/WPA2, WPA-PSK/WPA2-PSK, ERIP ⟨ 20dBM 2.4-2.4835GHz |
N/A | N/A |
| Wireless Functions | N/A | N/A | Enable/Disable Wireless Radio,WDS Bridge, WMM, Wireless Statistics WIFI Access Control List(ACL) , WPS(PIN/PBC) |
N/A | N/A |
| Signal Rate | N/A | N/A | 11n: Up to 300Mbps(dynamic) 11g: Up to 54Mbps(dynamic) 11b: Up to 11Mbps(dynamic) |
N/A | N/A |
| Power Outlet | N/A | N/A | N/A | (EU)100-240VAC, 16A, 50/60Hz (US)100-120VAC, 15A, 60Hz (UK)100-240VAC, 13A, 50/60Hz (FR)100-240VAC, 16A, 50/60Hz (CH)100-240VAC, 10A, 50/60Hz (AU)100-240VAC, 10A, 50/60Hz Noise Filter Insertion Loss : Up to 35dB at 1MHz – 40MHz |
|
| Cloud service | iOS/Android | ||||
| Dimensions | 69x50x22mm | 82x53x31mm | 84x56x41mm | 101x63x39mm | 120x66x39mm |
| Weight | 72 g | 103 g | 106 g | 184 g | 210 g |
| Certification | FCC/CE/LVD | CE/LVD | |||
| Power Consumptionabout 3.8W | about 3.8W | about 3.8W | about 7W | about 3.8W | about 6W |
| EuP | Meet the 2013 (<0.5W) | ||||
| TR069 | no | yes | yes | yes | yes |
| SmartLink | no | yes | no | no | no |
.
| Model No. | G671/G672 | G771 |
|---|---|---|
| Product Name | PLC+POE Hybrid Adapter, Indoor | PLC+POE Hybrid Adapter, Outdoor |
| PHY Rate | 600Mbps | |
| Effect Data Rate | TCP: ≤ 95 Mbps effective throughput UDP: ≤ 95Mbps effective throughput |
|
| Frequency Band | 2~68 MHz (With Mask) | |
| 95% Coverage UDP Throughput | 30Mbps | |
| Access Methods | Priority-based CSMA/CA channel access | |
| QoS | 4 Levels priority based contention access and multi segment bursting 8-levels VLAN priority field, TOS Field QoS Classification by destination MAC address and IP Port |
|
| Modulation | OFDM (QAM 8/16/64/256/1024, QPSK, BPSK, ROBO) | |
| Nodes | Up to 7 PLC devices in 1 power circuit | |
| IGMP | Support for IPv4/IGMPv1,v2,v3 snooping Support for IPv6 and MLDv1,v2 snooping |
|
| Encryption | 128-bit AES Link Encryption with key management | |
| Standards | IEEE 802.3, IEEE 802.3U, IEEE1901 and HomePlug AV2 compliant | |
| Port | One 10/100M Ethernet port | |
| Distance | AC Wire : 300 meters | |
| LEDs | Power Indicator(Green) Powerline Indicator(Green/Orange/Red) Ethernet Indicator (Orange) |
|
| Temperature (Humidity) |
Operating : 5~40°C (10~90% Non-Condensing) Storage : 0~50°C (5~90% Non-Condensing) |
|
| Power Source | 100~240 VAC, 50/60 Hz | |
| POE Power | Single IEEE 802.3af POE type Single port Endpoint PSE, Alternative B POE Output Class 0, 1, 2, 3, 4 PoE available on RJ-45 ports via Ethernet twisted pair cabling on port pins 4,5(+), 7,8(-). Uses spare pairs, not data pairs. PoE Ports Output voltage: (G671)nominal 48 VDC, deliver 7W to the PD. (G672)nominal 48 VDC, deliver 15.4W to the PD. |
Single IEEE 802.3af POE type Single port Endpoint PSE, Alternative B POE Output Class 0, 1, 2, 3, 4 PoE available on RJ-45 ports via Ethernet twisted pair cabling on port pins 4,5(+), 7,8(-). Uses spare pairs, not data pairs. PoE Ports Output voltage: nominal 48 VDC, deliver 15.4W to the PD. |
| Power cord | 0.9m AC Power cord | |
| Dimensions | 122x68x39mm | |
| Weight | 171 g | |
| Power Consumption | About 9.5W | About 18W |
| Certification | CE/LVD | |
| EuP | Meet the 2013 (⟨0.5W) | |
| TR069 | Yes | |
| Model No. | GK550 | GK556 | GK558 |
|---|---|---|---|
| Product Name | SmartLINK Ethernet Adapter | SmartLINK Hybrid Adapter(WiFi + PLC) | SmartLINK Plugthrough Adapter |
| PHY Rate | 1.3 Gbps | ||
| Effect Data Rate | TCP: ≤ 480 Mbps effective throughput UDP: ≤ 600 Mbps effective throughput |
||
| Frequency Band | 2~68 MHz (With Mask) | ||
| 95% Coverage UDP Throughput | 50Mbps | ||
| Access Methods | Priority-based CSMA/CA channel access | ||
| QoS | Integrated Quality of Service (QoS) Enhancements Hardware Packet Classifiers for ToS, CoS and IP Port QoS Classification by destination MAC address and IP Port |
||
| Modulation | OFDM (Supports OFDM 4096/1024/256/64/16/8-QAM,QPSK, BPSK and ROBO Modulation Schemes) | ||
| Nodes | Active/Total:63/128 nodes 4 overlapping networks for neighbor networks with CCo failover Max 128 bridged devices per station Up to 4096 addressable devices including bridged devices |
||
| IGMP | Supports IGMP managed multicast sessions IGMP snooping with multicast to multiple unicast IGMP/MLD Address filtering |
||
| Encryption | 128-bit AES Link Encryption with key management | ||
| Standards | IEEE 802.3, IEEE 802.3U, IEEE1901 and HomePlug AV2 with MIMO | ||
| Port | One 10/100/1000M Ethernet port | ||
| Distance | AC Wire : 300 meters | ||
| LEDs | Power Indicator(Green) Powerline Indicator(Green/Orange/Red) Ethernet Indicator (Green) |
Power Indicator(Green) Powerline Indicator(Green/Orange/Red) WiFi Indicator (Green) Ethernet 1,2 Indicator (Green) |
Power Indicator(Green) Powerline Indicator(Green/Orange/Red) Ethernet 1,2,3 Indicator (Green) |
| Temperature (Humidity) |
Operating : 5~40°C (10~90% Non-Condensing) Storage : 0~50°C (5~90% Non-Condensing) |
||
| Power Source | 100~240 VAC, 50/60 Hz | ||
| Push Button | Setting button for Network Security Management Reset butto |
Setting/PLC Reset Button WPS/ WiFi Reset Button |
Setting button for Network Security Management Reset butto |
| WiFi Standards | N/A | IEEE802.11ac, IEEE 802.11n, IEEE 802.11g, IEEE 802.11b 64/128/152-bit WEP/WPA/WPA2,WPA-PSK/WPA2-PSK EIRP ⟨20dBm 2.4GHz and 5GHz Dual-band 2.4G: 2T2R 802.11n(300 Mbps) 5G: 2T2R 802.11n/11ac(300Mbps/433Mbps) |
N/A |
| Wireless Functions | N/A | Enable/Disable Wireless Radio, WDS Bridge, WMM, Wireless Statistics WIFI Access Control List(ACL) , WPS(PIN/PBC) |
N/A |
| Signal Rate | N/A | 11ac:Up tp 866Mbps(dynamic) 11n: Up to 300Mbps(dynamic) |
N/A |
| Signal Rate | N/A | N/A | (EU)100-240VAC, 16A, 50/60Hz (US)100-120VAC, 15A, 60Hz (UK)100-240VAC, 13A, 50/60Hz (FR)100-240VAC, 16A, 50/60Hz (CH)100-240VAC, 10A, 50/60Hz (AU)100-240VAC, 10A, 50/60Hz Noise Filter Insertion Loss : Up to 35dB at 1MHz – 40MHz |
| Dimensions | 82x53x31mm | 70x70x165mm | 66x120x39mm |
| Weight | 100 g | 500 g | 210 g |
| Power Consumption | About 3W | About 10W | About 7W |
| Certification | CE/LVD | ||
| EuP | Meet the 2013 (<0.5W) | ||
| TR069 | Yes | ||
| SmartLink | Yes | ||
